Fully Innovative
Fully Solarwin Design
Aluminum panels can open desired angle and providing daylight, ventilation and shading. With opening angle panels prevent water in a rainy weather while ventilating indoor. All kinds of interior lighting and heating system can be applied in the ceiling.
General Features
- The system works with 5% slope.
- Single unit can be built up to 50 m2 area.
- Rain evacuate by the gutters which are on the panel. Water resistant.On the system Epdm gasket is using.
- The system can be built as a single unit up to a width of 8 m and unlimited area shading can be added by adding multiple units.
- System’s horizontal load bearing columns must be placed every 300 cm.
- All profiles and accessories are stainless. The load-bearing profiles are 100 * 100 * 4 mm and 60 * 120 * 4 mm. Steel construction is not required.
- The system can work all kind of unbalanced surfaces;Columns can adjust themselves and sytem Works properly.
- The system has 425 W of 120 nm torque and 880 W of 300 nm torque motors. System security is provided by motion sensor switches.
- Standard color is storm blue (Ral 7016) column and panel (Ral 9001) color is cream. It can be apply for all other colors.
- Spare parts are guaranteed for 2 years.
